Part Number = 73_1227 -- Reference Number -- 51 -- Clip-airspeed tube attachment, LH, 5 req.

Part Number = 75_1200 -- Reference Number -- 1 -- Wing assy, covered, LH grade A, all new FAA-PMA wood û exchange hardware

Part Number = 75_1200_1 -- Reference Number -- 1 -- Wing assy, covered, RH grade A, all new FAA-PMA wood û exchange hardware

Part Number = 75_1201 -- Reference Number -- 1 -- Wing assy, LH, all new FAA-PMA wood û exchange hardware

Part Number = 75_1201_1 -- Reference Number -- 1 -- Wing assy, RH, all new FAA-PMA wood û exchange hardware

Part Number = 75_1272_1 -- Reference Number -- 78 -- Plate-lift wire tunnel, LH

Part Number = 75_1272_2 -- Reference Number -- 78 -- Plate-lift wire tunnel, RH

Part Number = 75_1272_3 -- Reference Number -- 79 -- Plate-lift wire tunnel, LH

Part Number = 75_1272_4 -- Reference Number -- 79 -- Plate-lift wire tunnel, RH

Part Number = 75_1273 -- Reference Number -- 80 -- Stud-cover plate, 3 req.

Part Number = AG75_1118 -- Reference Number -- 55 -- Frame assy-inspection opening, 5 req., per wing

Part Number = AG75_1119 -- Reference Number -- 57 -- Window-inspection, 5 req., per wing

Part Number = AG75_1158_2 -- Reference Number -- 81 -- Spoiler-leading edge lower wing

Part Number = AG75_1203 -- Reference Number -- 2 -- Spar assy with plates, not glued, drilled, lower rear LH

Part Number = AG75_1203_1 -- Reference Number -- 2 -- Spar assy with plates, not glued, drilled, lower rear RH

Part Number = AG75_1204 -- Reference Number -- 3 -- Spar assy with plates, not glued, drilled, lower front LH

Part Number = AG75_1204_1 -- Reference Number -- 3 -- Spar assy with plates, not glued, drilled, lower front RH

Part Number = AG75_1205 -- Reference Number -- 29 -- Rib assy-main lower wing, 2 req., LH or RH

Part Number = AG75_1206 -- Reference Number -- 23/27 -- Rib assy-aileron cutaway, 9 req., LH & RH

Part Number = AG75_1207 -- Reference Number -- 30 -- Rib assy-walkway #1, LH

Part Number = AG75_1207_1 -- Reference Number -- 30 -- Rib assy-walkway #1, RH

Part Number = AG75_1207_27K -- Reference Number -- 35 -- Lower root rib installation kit, LH or RH

Part Number = AG75_1208 -- Reference Number -- 32 -- Rib assy-walkway #2, LH

Part Number = AG75_1208_1 -- Reference Number -- 32 -- Rib assy-walkway #2, RH

Part Number = AG75_1209 -- Reference Number -- 33 -- Rib assy-walkway #3, LH

Part Number = AG75_1209_1 -- Reference Number -- 33 -- Rib assy-walkway #3, RH

Part Number = AG75_1210 -- Reference Number -- 25 -- Rib assy-inboard of aileron root, not boxed, LH

Part Number = AG75_1210_1 -- Reference Number -- 25 -- Rib assy-inboard of aileron root, not boxed, RH

Part Number = AG75_1210B -- Reference Number -- 25 -- Rib assy-inboard of aileron root, boxed, LH

Part Number = AG75_1210B_1 -- Reference Number -- 25 -- Rib assy-inboard of aileron root, boxed, RH

Part Number = AG75_1211 -- Reference Number -- 24/27 -- Rib assy-adj. to strut point lower, 2 req., LH & RH

Part Number = AG75_1215 -- Reference Number -- 26 -- Rib assy-lower tip #1, LH & RH

Part Number = AG75_1216 -- Reference Number -- 28 -- Rib assy-lower tip #2, LH & RH

Part Number = AG75_1219 -- Reference Number -- 10 -- Strut assy, root compression

Part Number = AG75_1246LE -- Reference Number -- 53/58 -- Aluminum leading edge kit-lower wing LH or RH

Part Number = AG75_1253 -- Reference Number -- 62/63 -- Aluminum trailing edge-6061T-6 extrusion, 12Æ

Part Number = AG75_1255 -- Reference Number -- 75 -- Binder, aluminum-wing walk trailing edge

Part Number = AG75_1256_1 -- Reference Number -- 76 -- Binder, aluminum-wing walk outboard edge

Part Number = AG75_1256_2 -- Reference Number -- 77 -- Binder, aluminum-wing walk leading edge

Part Number = AG75_1257_16 -- Reference Number -- 52 -- Brace kit-lower wing bow, LH or RH, includes gussets

Part Number = AG75_1257_2 -- Reference Number -- 52 -- Cover-plywood, lower wing tip leading edge, top LH or RH

Part Number = AG75_1257_3 -- Reference Number -- 52 -- Cover-plywood, lower wing tip leading edge, bottom LH or RH

Part Number = AG75_1258_AK -- Reference Number -- 60/61 -- Aluminum former kit-aileron gap, LH or RH

Part Number = AG75_1258_TE -- Reference Number -- 59 -- Wood stringer-inboard aileron bay, pre-shaped, 10Æ

Part Number = AG75_1260 -- Reference Number -- 68 -- Door assy-aileron idler inspection, anodized

Part Number = AG75_1260_3 -- Reference Number -- 70 -- Hinge half-idler door inspection

Part Number = AG75_1260_4 -- Reference Number -- 71 -- Pin-idler door hinge

Part Number = AG75_1261 -- Reference Number -- 72 -- Door assy-aileron bellcrank inspection, anodized

Part Number = AG75_1262 -- Reference Number -- 73 -- Door assy-wing root inspection, anodized

Part Number = AG75_1263_2 -- Reference Number -- 64 -- Frame installation kit assy, aileron idler inspection door LH

Part Number = AG_1263_3 -- Reference Number -- 64 -- Frame installation kit assy, aileron idler inspection door RH

Part Number = AG75_1264 -- Reference Number -- 66 -- Frame installation kit assy-aileron Bellcrank inspection door, LH

Part Number = AG75_1264_1 -- Reference Number -- 66 -- Frame installation kit assy-aileron Bellcrank inspection door, RH

Part Number = AG75_1264_2 -- Reference Number -- 67 -- Bracket assy with dzus spring-aileron Bellcrank inspection door, LH or RH

Part Number = AG75_1270 -- Reference Number -- 74 -- Mat-wing walk, LH

Part Number = AG75_1270_1 -- Reference Number -- 74 -- Mat-wing walk, RH

Part Number = AG75_1276 -- Reference Number -- 31 -- Dzus bracket assy, rear

Part Number = AG75_1277 -- Reference Number -- 65 -- Plate assy-dzus spring support

Part Number = AG75_3862_17 -- Reference Number -- 49 -- Line assy-drain tee to strut point, static, LH

Part Number = AG75_3862_18 -- Reference Number -- 50 -- Line assy-drain tee to strut point, pitot, LH

Part Number = AGE75N1_1202_F1 -- Reference Number -- 34 -- Wing walk, lower wing, RH, preformed on leading edge

Part Number = AGE75N1_1202F -- Reference Number -- 34 -- Wing walk, lower wing, LH, preformed on leading edge

Part Number = E75N1_1202 -- Reference Number -- 34 -- Wing walk, lower wing, LH

Part Number = E75N1_1202_1 -- Reference Number -- 34 -- Wing walk, lower wing, RH
