elevator_control_figure_46a

Part Number = 201_KS -- Reference Number -- 6 -- Bearing-AG73-3301

Part Number = 73_3302_2 -- Reference Number -- 15 -- Socket assembly-front

Part Number = 73_3302_3 -- Reference Number -- 11 -- Socket assembly-rear stick

Part Number = 75_3352 -- Reference Number -- 3 -- Horn-aileron control

Part Number = AG75_3360 -- Reference Number -- 12 -- Stick-wood, control front or rear (stick only)

Part Number = AG75_3360_M -- Reference Number -- 12 -- Stick-metal, control front or rear (stick only)

Part Number = 75_3362_1 -- Reference Number -- 11,12 -- Stick & socket assembly-rear, wood

Part Number = 75_3362_1M -- Reference Number -- 11,12 -- Stick & socket assembly-rear, metal

Part Number = 75_3362_2 -- Reference Number -- 15,16 -- Stick & socket assembly, wood, front

Part Number = 75_3362_2M -- Reference Number -- 15,16 -- Stick & socket assemlby, metal, front

Part Number = AG73_3310 -- Reference Number -- 9 -- Bearing housing-front

Part Number = AG75_3301 -- Reference Number -- 4 -- Bearing housing-rear

Part Number = AG75_3326_1 -- Reference Number -- 13 -- Bolt-control stop, 2 required

Part Number = AG75_3336 -- Reference Number -- 5 -- Washer-felt, AG73-3310

Part Number = AG75_3353 -- Reference Number -- 2 -- Tube assembly-control stick torque

Part Number = AG75_3358 -- Reference Number -- 8 -- Shield-bearing dust, AG73-3310

Part Number = AG75_3359 -- Reference Number -- 7 -- Washer-felt, AG73-3310
