stabilizer_figure_11a

Part Number = 75_1700 -- Reference Number -- 1 -- Stabilizer assembly-covered, C-102

Part Number = 75-1701 -- Reference Number -- 1 -- Stabilizer assembly-uncovered

Part Number = 75_1737 -- Reference Number -- 8 -- Shackle-stabilizer, front uppper, 2 required

Part Number = 75_1739 -- Reference Number -- 9 -- Shackle-stabilizer, front lower, 2 required

Part Number = 75_1741 -- Reference Number -- 10 -- Shackle-stabilizer, rear lower, 2 required

Part Number = 75_1751 -- Reference Number -- 1 -- Stabilizer assembly-uncovered

Part Number = AG75_1705_2 -- Reference Number -- 4 -- Cover-stabilizer leading edge left tip

Part Number = AG75_1705_3 -- Reference Number -- 5 -- Cover-stabilizer leading edge right tip

Part Number = AG75_1705_4 -- Reference Number -- 2 -- Cover-stabilizer leading edge, LH

Part Number = AG75_1705_5 -- Reference Number -- 3 -- Cover-stabilizer leading edge, RH

Part Number = AG75_1707_1 -- Reference Number -- 14 -- Strip-stabilizer fabric, 2 required

Part Number = AG75_1707_2 -- Reference Number -- 15 -- Strip-stabilizer fabric, 2 required

Part Number = AG75_1707_3 -- Reference Number -- 16 -- Strip-stabilizer fabric, 2 required

Part Number = AG75_1707_4 -- Reference Number -- 17 -- Strip-stabilizer fabric, 2 required

Part Number = AG75_1727 -- Reference Number -- 11 -- Window-brace wire inspection, 2 required
